- straight adjustable hook
- support foot
- disc section
- toothed disc Φ460 mm
- maintenance-free hub
- rubber protection of each plate
- steel pack roller Φ600 mm
- wheels 340 / 55-16
- varnish coat with enhanced parameters

- air or hydraulic brakes
- Cambridge roller Φ500 / 530/600
- zig-zag roller Φ530 mm
- front sharp roller 7 pcs of replaceable hardox knives hydraulically adjustable
- hydraulically adjustable front spring harrow
- LED lighting



















roller to your needs


FRONT OPTIONS
sharp roller | cross board
OX in front of the disc section can be equipped with a knife shaft consisting of 7 hardox knives, it is used for straw cutting and intensive grinding of maize and rape crop residues and green mass of aftercrop plants | instead of the knife shaft, the machine can be equipped with a spring harrow | both sections are hydraulically adjustable


DISC SECTION
toothed disc Φ460 mm
two disc beams as one section of toothed discs with a maintenance-free hub, as well as rubber protections are used for undercutting and mixing stubble and harvest residues, thanks to which OX leaves a crumbled, compacted soil behind with the best conditions for sowing
Technical data
![]() |
|m| | 4,2 | 6,2 |
![]() |
|id| | 4126 | 4127 |
![]() |
|kg| | 3540 | 5100 |
![]() |
|KM| | 170 | 240 |
![]() |
|szt.| | 34 | 50 |
![]() |
|szt.| | 34 | 50 |
![]() |
|m| | 4,2 | 6,2 |
![]() |
|id| | 4120 | 4121 |
![]() |
|kg| | 4040 | 5820 |
![]() |
|KM| | 140 | 210 |
![]() |
|szt.| | 79 | 119 |
![]() |
|szt.| | 34 | 50 |
![]() |
|m| | 4,2 | 6,2 |
![]() |
|id| | 4122 | 4123 |
![]() |
|kg| | 4370 | 6300 |
![]() |
|KM| | 140 | 210 |
![]() |
|szt.| | 85 | 125 |
![]() |
|szt.| | 34 | 50 |
![]() |
|m| | 4,2 | 6,2 |
![]() |
|id| | 4124 | 4125 |
![]() |
|kg| | 4560 | 6570 |
![]() |
|KM| | 160 | 230 |
![]() |
|szt.| | 79 | 119 |
![]() |
|szt.| | 34 | 50 |
![]() |
|m| | 4,2 | 6,2 |
![]() |
|id| | 4128 | 4129 |
![]() |
|kg| | 4590 | 6615 |
![]() |
|KM| | 180 | 250 |
![]() |
|szt.| | 82 | 122 |
![]() |
|szt.| | 34 | 50 |
